86 Inch LED Interactive Whiteboard 65 75 98 Smart Multi Touch Display

Basic Information
Place of Origin: China
Brand Name: iBoard
Certification: CE FCC Rohs
Model Number: TE-QS
Minimum Order Quantity: 1 piece
Price: USD1100-USD3899 per pieces
Packaging Details: Export Cartons
Delivery Time: 25 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000 pieces per month
Type: Infrared Interactive Flat Panel, LCD Touch Screen Interface Type: USB,D-Sub,DVI,Serial,VGA,HDMI, Etc
Resolution: 3840*2160 Touch Points: 10~20 Points
Color: Black, Grey, Silver (Other Colors Optional ) Application: Teaching,meeting,HOME,training,education
Operating System: Android, Windows, Mac, IOS... Material: Aluminum Alloy Frame
High Light:

86'' LED Interactive Whiteboard

,

Infrared LED Interactive Whiteboard

,

350 cd/m2 Smart multi Touch Display

86 inch LED Interactive Whiteboard 65 75 98 inch Smart multi Touch Display

Description of Touch Screen Monitor

Interactive Touch Display is a computer driven device, allowing users to access and manipulate electronic files by means of a LCD display. The interactive LCD will be connected to a computer with USB, and the computer then connected back to the LCD with a video cable.It is as known as interactive screen,  interactive whiteboard, smart whiteboard, touch screen display,  touch monitor,  LED touch monitor,  touch interactive display, interactive flat panel display,  touchscreens , etc.

Fit for School Classroom, office, conference presentation, Trainning, annotation ect. Built in Android, come with OPS slot for windows system. Camera& mic optional.



We have a strong R&D team and our IFPD is independently developed and produced, integrates LED display, computer, speaker, electronic whiteboard, TV and other functions in one. With various experience on making OEM/ODM interactive flat panels and interactive whiteboard, products sold to more than 80 countires in the world.



Own developed Infrared technology

ODM/OEM Support

SKD support

Customized size

Easy for after-sales service

Shortest delivery time

Good quality in this field



Specs for IFPD

Model TE-QS-65 TE-QS-75   TE-QS-86
Dispaly Backlight D-LED Backlight
Resolution 3840*2160 3840*2160 3840*2160
Brightness 350 cd/㎡ 350 cd/㎡ 350 cd/㎡
Contrast 1200:1 or higher 1200:1 or higher 1200:1 or higher
Screen Size(mm) 1428.5*803.5 1649.7*927.9 1895.04*1065.96
Aspect Ratio 16:9
View Angle 178°
Screen Mode 16:9/4:3/dot to dot/full screen
Color Depth 10bit, 1.07Billon colors 10bit, 1.07Billon colors 10bit, 1.07Billon colors
Panel Response Time 8ms 8ms 8ms
Suport Resolution 1280*960/1280*1024/1360*768/1440*900/1600*1200/1920*1080/3840*2160@60HZ





Android Specification

Android 11.0

Ram: 2G/4G/8G
Storage: 16G/32G/64G
I/O Ports Please contact us to know more detail specification
Front Button POWER,SOURCE,MENU,VOL+,VOL-,CH+,CH-,...etc
Built in camera 13 Mega Pixels (Optional)
Built in Microphone 4 /6/8 array microphones (Optional)
Voltage AC(100~240)V-50/60HZ
Power Range Standby Power<1W Standby Power<1W Standby Power<1W
Rated Power<230W Rated Power<350W Rated Power<415W









Touch Parameter

Touch Technology Infared Touch
Touch Points 10/20 touch points
Writing Mode Finger or any opaque object
Accuracy <2mm
Response Time 4~8ms
Cusor Speed 180 dot/s
Connection Port USB(full speed)
Operating System Windows/Linux/Mac/Android
Working Temperature 0℃-40℃



Remark: For more details of the specification , please contact us to know more detials.
