| Place of Origin: | China |
|---|---|
| Brand Name: | iBOARD |
| Certification: | CE,FCC,ROHS,CCC,etc. |
| Model Number: | TE-QS-65 |
| Minimum Order Quantity: | 10PCS |
| Price: | USD750-800 |
| Packaging Details: | 1pc/carton, optional to be with wooden crate or pallet |
| Delivery Time: | 15-20 working days |
| Supply Ability: | 5000pcs per month |
| Android Version: | 11 | CPU: | A73*4+A53*4@2.28G |
|---|---|---|---|
| Flash: | 64G EMMC | RAM: | 6G DDR3 |
| Front Keys: | 8 Or OEM | Touch Technology: | IR Touch |
| Touch Mode: | Finger Or Pen | Applications: | School/office/video Meeting/training/presentation |
| OPS: | Optional To Be Built In | Camera: | Optional To Be Built In Or Out-connected |
| MIC: | Optional To Be Built In | ||
| High Light: | Android 11 IR Interactive Whiteboard,Touch Frame Optional Board Display,Type-C IR Interactive Whiteboard |
||
Iboard's new android version 11 launched! We have 2+16G/4+32G/6+64G optional.
Supporting Android/Windows/Mac./Linux os.
Available for school/office/video meeting/training/presentation,etc.
OEM and ODM service available.
| Model | TE-QS-65 | TE-QS-75 | TE-QS-86 | |
| Dispaly Backlight | D-LED | |||
| Resolution | 3840*2160 | |||
| Brightness | 350 cd/㎡ | |||
| Contrast | 1200:1 or higher | |||
| Screen Size(mm) | 1428,5x803,5 | 1650x928 | 1895,04x1065,96 | |
| Aspect Ratio | 16:9 | |||
| View Angle | 178° | |||
| Screen Mode | 16:9/4:3/dot to dot/full screen | |||
| Color Depth | 10bit, 1.07Billon colors | |||
| Panel Response Time | 8ms | |||
| Suport Resolution | 4K Ultra HD 3840x2160 | |||
|
Android Specification |
Android 11.0 | |||
| A53*4, default 1.55G, Mali G52 | ||||
| Ram: 2G DDR3 | ||||
| Storage: 16G EMMC | ||||
| Full support for Full HD and 4K relosution (with OPS slot working with 4k 60Hz); | ||||
| The file manager is supported | ||||
| Screen sharing aplication is supported | ||||
| Local and online supportfor music player. | ||||
| Input Ports |
Rear: 2*HDMI2.0(up to3840*2160/60Hz), 1*VGA+AUDIO, 1*YPBPR , 1*AV IN, 1*MIC, 2*USB 2.0, 1*TOUCH-USB, 1*RS232, 1*TF CARD, 1*LAN IN(10M/100M), 1*WIFI(2.4G/5G), 1*BT( support 5.0), 1*OPS slot(up to3840*2160/60Hz) Front: 1*HDMI(Max support 3840*2160/60Hz), 1*TOUCH USB, 3*USB 2.0 ,Type C optional. |
|||
| Output Ports | 1*SPDIF,1*EARPHONE,1*AV OUT | |||
| Front Button | 8 KEYS (POWER,SOURCE,MENU,VOL+,VOL-,HOME,ENTER, ES) | |||
| Speakers | 2x 15w | |||
| Voltage | AC(100～240)V-50/60HZ | |||
| Power Range | Standby Power<1W | Standby Power<1W | Standby Power<1W | |
| Rated Power<230W | Rated Power<350W | Rated Power<415W | ||
|
Touch Parameter |
Infared Touch | |||
| Touch Points | 20 touch points | |||
| Writing Mode | Finger or any opaque object | |||
| Accuracy | <2mm | |||
| Response Time | 5ms | |||
| Cusor Speed | 180 dot/s | |||
| Connection Port | USB 2.0 | |||
| Operating System | Windows/Linux/Mac/Android | |||
| Working Temperature | 0℃-40℃ | |||
| Accessories | Magnetic Pens*2, HDMI Cable*1, Touch USB cable, Power Cable*1, whiteboard Software *1, Remoter*1, Wall mounting bracket | |||
| Sizes(mm) | 1486*905*93.2 | 1707x1030x93.2 | 1954x1168x93.2 | |
| Weights (kgs) | 41 / 54 | 54/ 71 | 70/ 88 | |
|
Carton Sizes (mm) (LxHxW ) |
1646x1074x240 | 1873x1204x240 | 2120x1353x240 | |
|
1x 20GP ( Loading reference) |
58 pcs | 29 pcs | 24 pcs | |
|
1X40HQ ( Loading reference) |
126 pcs | 112 pcs | 49 pcs | |
With powerful annotation software, available to share by QR code/email/Cloud.
