Place of Origin: | CHINA |
---|---|
Brand Name: | iBoard |
Certification: | CE/FCC/ROHS |
Model Number: | YL-75 |
Minimum Order Quantity: | 1 Piece |
Price: | USD700 - USD1800/unit |
Packaging Details: | Carton or wooden packaging, oem available |
Delivery Time: | 15-25 Working Days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 20000 units/month |
Brand Name: | IBoard Or OEM | Color: | Black And Silver |
---|---|---|---|
Built-in Camera: | Support 2K Or 4K | Brightness: | ≥350cd/m² |
Touch Technology: | Infrared Touch | Touch Ways: | Finger Or Any Opaque Objects |
Touch Points: | 10 Points Or More | Support OPS: | Yes, One OPS Slot (Optional) |
Highlight: | TFT LED 75 Interactive Touch Screen Monitor,Android8 Interactive Touch Screen Monitor,Android8 75 interactive touch screen |
Standard Model (Non-Air Gap) |
TE-YL5S-65 |
TE-YL5S-75 |
TE-YL5S-86 |
|
Conference Model |
TE-YL6-65 |
TE-YL6-75 |
TE-YL6-86 |
|
Dispaly Backlight |
D-LED Backlight |
|||
Resolution |
3840*2160 |
3840*2160 |
3840*2160 |
|
Brightness |
350 cd/㎡ |
350 cd/㎡ |
350 cd/㎡ |
|
Contrast |
1200:1 or higher |
1200:1 or higher |
1200:1 or higher |
|
Screen Size(mm) |
1428,5x803,5mm |
1650x928mm |
1895,04x1065,96mm |
|
Aspect Ratio |
16:9 |
|||
View Angle |
178° |
|||
Screen Mode |
16:9/4:3/dot to dot/full screen |
|||
Color Depth |
10bit, 1.07Billon colors |
10bit, 1.07Billon colors |
10bit, 1.07Billon colors |
|
Panel Response Time |
8ms |
8ms |
8ms |
|
Suport Resolution |
4K Ultra HD 3840x2160 |
|||
AG Tempered Glass |
Yes for all models |
|||
Android Specification |
Android 11.0 |
|||
CPU A73*4+A53*4 2.28GHz |
||||
GPU G52*8 |
||||
Dual wifi card : WIFI 6+Bluetooth + WIFI 5G |
||||
RAM 8G DDR4 |
||||
EMMC 64G |
||||
Full support for Full HD and 4K relosution (with OPS slot working with 4k 60Hz); |
||||
The file manager is supported |
||||
Screen sharing application is supported |
||||
Local and online supportfor music player. |
||||
Input Ports |
Rear: HDMI x2 (4K@60Hz), USB2.0x1,USB 3.0 x2(OPS/Android access automatically), TOUCH USB x 2,TF card x1,RS232 x1,RJ45 x1,MIC x1,DP x1(4K@60Hz), VGA/Audio x1, TYPE-C x1(supports USB/touch/image/video 4K@60Hz/fast charge) |
|||
Front: USB3.0 x3(OPS/android/external PC access automatically,support OPS/Android 3.0, external PC 2.0),HDMI x1(4K@60Hz), TOUCH USB x1, TYPE-C x1(supports USB/touch/image/video 4K@60Hz/slow charge) |
||||
Output Ports |
HDMI OUT x1(4K@60Hz),SPDIF x1,Earphone x1, RJ45 out x1 |
|||
Front Button |
POWER SOURCE MENU VOL- VOL+ REC A.BLUE PC ES RATIO HOME |
|||
Voltage |
AC(100~240)V-50/60HZ |
|||
Power Range |
Standby Power<1W |
Standby Power<1W |
Standby Power<1W |
|
Rated Power<230W |
Rated Power<350W |
Rated Power<415W |
||
Touch Parameter |
Touch Technology |
Infared Touch |
||
Touch Points |
20 touch points for AndroidWindows |
|||
Writing Mode |
Finger or any opaque object |
|||
Accuracy |
<1mm |
|||
Response Time |
5ms |
|||
Cusor Speed |
180 dot/s |
|||
Connection Port |
USB 2.0, USB 3.0 |
|||
Operating System |
Windows/Linux/Mac/Android |
|||
Working Temperature |
0℃-40℃ |
|||
Accessories |
Magnetic Pens*2, HDMI Cable*1, Touch USB, Power Cable*1, Software download card*1, Remoter*1, Wall mounting bracket |
|||
Product sizes(mm) for standard Models |
1473*917.8*93.2 |
1700*1047.8*96.9 |
1946*1185.8*94 |
|
Product sizes(mm) for conference models |
1469.1*935.8*92.4 |
1695.6*1066.0*96.1 |
1942*1203.6*93.9 |
|
Built in 13MP Camera |
Default built in for Conference models TE-YL6 Series, other models without camera |
|||
Built in Array Microphone |
4 , 6, 8 array microphones built in for conference models, others models optional |
|||
Net Weights for Standard and Non-Air Gap Models |
APPX 40KG |
APPX 60KG |
APPX 75KG |
|
Net Weights for Conference Model |
APPX 42KG |
APPX 62KG |
APPX 78KG |
Our products meet the certification requirements of most of countries in the world and have complete certificates.
Exhibition:
FAQ:
1. Q: Are you a factory?
A: Yes, we are a factory. We're located in Shenzhen China.
2. Q: How can I trust your product quality?
A: Quality is what we put first over the last 15 years. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE & ROHS & ISO & FCC etc.
3. Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly.
4. Q: Do you have MOQ?
A: Generally, our MOQ is 1 pcs. But the larger the order is, the more discounts will be given.
5. Q: Could you offer the OEM&ODM service?
A: Yes, we can. We've been providing OEM&ODM service for many world-class companies for over 15 years.
6. Q: What's the leading time?
A: The leading time for sample would be 3-7 days. As for large order, it takes about 25 days.
