Micro USB Intelligent Pen 2.4GHz RF Wireless For Interactive Touch Panel Android Pen For Touch Screen Monitor
Product Details:
| Place of Origin: | Shenzhen, CHINA |
| Brand Name: | iBoard or OEM |
| Certification: | CCC, CE, FCC, RoHS, Reach, OHSAS, ISO9001, ISO14001 |
| Model Number: | EL18P |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | USD18 |
| Packaging Details: | Carton Package |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000 units per month |
|
Detail Information |
|||
| Product Name: | Intelligent Pen | Model: | EL18P |
|---|---|---|---|
| Head: | 8mm Or 3mm Infrared Nano Head | Data Transfer Method: | 2.4GHz RF Wireless |
| Port: | Micro USB | Working Current: | About 10mA |
| Frequency: | 2402~ 2480MHz | Transmission Rate: | 1 Mbps |
| Communication Distance: | Effective Range：15m | Operation System: | XP/WIN7/WIN8/WIN10，Android |
| Compatible Interface: | USB2.0, USB1.1，USB3.0 | Type: | Electronic Laser |
| Aspect Radio: | 16:10, 16:9... | Interface: | USB, VGA, RS232, HDMI |
| Screen Size: | 65",75",86", 98" | Multi-Touch: | Up To 40 Points |
| Hotkeys: | Two Sides Hotkeys | Shipping Way: | Sea Shipping Air Freight Truck Freight |
| Touch Points: | 20 Points | Warranty: | 1 Year |
| Power Supply: | AC 100-240V, 50/60Hz | Operation System: | Andriod/Windows/Linux/Mac.etc. |
| Accuracy: | 2mm | Mobile Stand: | Optional |
| Colors: | Black Or OEM | ||
| Highlight: | Micro USB Interactive Touch Screen Monitor,Android Pen Interactive Touch Screen Monitor |
||
Product Description
Micro USB Intelligent Pen 2.4GHz RF wireless For Interactive Touch Panel Android Pen for Touch Screen Monitor
Specification
Product Name: Intelligent pen/smart pen
Model No.: EL18P
(Electronic Laser)
| Head | 8mm or 3mm infrared nano head |
| Data transfer method | 2.4GHz RF wireless |
| Port | Micro USB |
| Power source | Built-in 150mAh lithium battery |
| Working current | About 10mA |
| Frequency | 2402~ 2480MHz |
| Transmission rate | 1 Mbps |
| Receive sensitivity | 5 ~ -40 dBm |
| Working temperature | -30 ~ 55°C |
| Communication distance | Effective range:15m |
Receiver:
| Operation system | XP/WIN7/WIN8/WIN10,Android |
| Compatible interface | USB2.0, USB1.1,USB3.0 |
| Voltage | USB(4.5-5.5V) |
