| Place of Origin: | CHINA |
|---|---|
| Brand Name: | IBOARD |
| Certification: | CE,ROHS,FCC,EDLA,etc. |
| Model Number: | TE-YL-86 |
| Minimum Order Quantity: | 1PC |
| Price: | 1100-1400USD/PC |
| Packaging Details: | 1pc/carton box, optional to be with wooden crate |
| Delivery Time: | 15-18 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000pcs/month |
| Android Version: | 13 | Touch Technology: | Infrared Touch |
|---|---|---|---|
| Touch Points: | 10/20/40/50 Points Optional | WIN OS: | Optional To Be With 10/11 Pro Actived |
| Workable Size: | 55/65/75/86/98/105/110 Inch | Applications: | School Teaching/education Equipment/video Meeting/presentation,etc. |
| Material: | Aluminum Frame | ||
| High Light: | Android 13 Iboard Interactive Whiteboard,Win 10 Iboard Interactive Whiteboard,Classroom finger touch interactive whiteboard |
||
Iboard Interactive Whiteboard Win 10 Android 13 Finger Touch TV Display 65 75 86 Inch For Classroom Business Meeting
IBOARD ANDROID 13 EDLA Certified Touch Panel display,optional to be with Windows 10/11 Pro actived
1. supporting wireless share upto 9 screens at one time
2.supporting multi finger pen touch with optional 10/20/40/50 points for android/windows OS
3.with iboard whiteboard software for annotation/share/record/meeting room,hand writing recognization into text,etc.
4. Android 13 with RAM and ROM optional: 4+32G/8+64G/8+128G
5.Available size: 55/65/75/86/98/105/110 inch
6.Packing:1pc/carton, optional to be with wooden crate
7.Certificates: CE/ROHS/FCC/CB,etc. we also available to support to do the cetificates needed for importing and exporting.
Specification sheet:
| Item | Android 13 Iboard Interactive Whiteboard Win Touch Panel Display Smart Monitor For Education Teaching |
| Model | TE-YL-86 |
| Display size(mm) | 1896.5*1066.5 |
| Display backlight |
D-LED Backlight
|
| Resolution | 3840*2160 |
| Brightness |
400 cd/㎡
|
| Contrast ratio | 4000:1 |
| Aspect ratio | 16:9 |
| Screen mode |
16:9/4:3/dot to dot/full screen
|
| Panel response time | 6ms |
| Android version | 13
A76*4(2.4GHz)+A55*4(1.8GHz)
RAM 8G or 16G
EMMC 128G / 256G
|
| Input ports |
Rear: TF card *1, USB 2.0 *1, USB 3.0 *2, DP *1 , TYPE-C * 1,HDMI IN *3, TOUCH
USB * 1, , LAN IN*1 , RS232 * 1, MIC IN *1
Front: USB3.0 * 3 (OPS/android/external PC access automatically,support OPS/Android
3.0, external PC 2.0),HDMI IN 2.0 *1(4K@60Hz), TOUCH USB * 1,
TYPE-C *1
|
| Output ports |
HDMI OUT *1,OPTICAL *1,EARPHONE *1, RJ45 OUT *1, TYPE-C OUT *1
|
| Front keys |
POWER SOURCE MENU VOL+ VOL- HOME ENTER ES
|
| Voltage |
AC(100～240)V-50/60HZ
|
| Touch technology | Infrared touch |
| Writing mode |
Finger or any opaque object
|
| Operation system | Android/Windows/Linux/Mac. |
| Camera | Optional to be built-in or out-connected for 13mp /8mp /48mp camera |
| Microphone | Optional to be built-in or out-connected for 4/6/8 array mic |
| Accessories | Touch Pen*2, HDMI cable*1, Touch USB cable*1,Power supply cable*1,Remote controller*1, Wall mounted kits*1 set,movable stand (optional) |
| Packing size | 2120*225*1320mm |
| N.W.(KGS) | 60 |
| G.W.(KGS) | 82 |
