LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch

Basic Information
Place of Origin: CHINA
Brand Name: IBOARD
Certification: CE/FCC/ROHS,etc.
Model Number: TE-QS-86
Minimum Order Quantity: 1PC
Price: USD1100-1400/PC
Packaging Details: 1pc/carton, optional to be in wooden pallet or crate
Delivery Time: 15-18 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000PCS PER MONTH
Size: 55/65/75/86/98/105/110 Inch Android Os: 13
Win OS: Optional To Actived For 10 Or 11 Pro Contrast: 4000:1
Material: Aluminum Frame+backlight Display Packing: Carton Box
Brightness: 450cd/m2
High Light:

LCD Smart Board 86 Inch

,

USB Wifi Interactive Whiteboard

,

OPS Screen Wifi Interactive Whiteboard

LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch



LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 0LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 1

LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 2

Advantages features:

1.Panel has two WIFI connections
2.USB-C on the front support : touch , data, video projection and charging, one cable is enough when connect to a PC with type-C port.
3.One LAN in (RJ45-in) and one LAN out (RJ45-out) to provide internet to external device
4.iMagic MDM: an iBoard developed device management software on Android, to manage your IFPDs, support install/uninstall apps of IFPD remotely.
5.Optioanl built in 13MP camera and 4/6 ray MIC, with additional costs.

6.Size available:55/65/75/86/98/105/110 inch

7. Supporting wireless share upto 9 screens for pad/phone/laptop/IFPD

8.Applications: school/online teaching/presentation/training/office/business center,home,etc.

9.OEM ODM available.

LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 3

Data Sheet:

Item LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch
Model TE-QS-86
Dsiplay size (mm) 1897*1068.1
Resolution 3840*2160
Response time 6ms
Touch technology infrared touch
Contrast 4000:1
Speaker  2*15W
Glass 4mm tempered glass 7H hardness
Brightness 350cd/m2
Android OS

13 with 4+32G/8+64G

Dual 5.0GHz WiFi Moudle , one for WIFI, one for hotspot.

Ethernet 10/100/1000 network card with RJ45 connector.



Input ports Rear: 2*HDMI2.0, 1*VGA&AUDIO IN, 1*YPBPR, 2*USB 3.0, 1*USB2.0, 1*TOUCH-USB, 1*TF card, 1*RS232, 1*RJ45 IN, 1*AV IN, 1*MIC IN, 1*DP, 1*Type C(only for USB), 1*OPS SLOT
Front: 1*HDMI2.0, 1*TOUCH USB, 3*USB3.0, TYPE-C (Support Touch, Data, Video and Audio transfer, charging(standard 15W, optional 65W)
Ouput ports 1*HDMI-out, 1*COAXIAL, 1*Earphone, 1*RJ45 OUT, 1*AV OUT
Front keys 8KEY(POWER,SOURCE,MENU,VOL-,VOL+,HOME,ENTER, ES)
Camera or mic optional to be built-in for 8mp/13mp/48mp camera or 4/6/8mic
NFC function optional
Fingerprint function optional
Accessories touch pen*2, HDMI cable*1, Touch USB cable*1, power supply cable, remote controller *1.wall mounted bracket*1 set, movable stand (optional)
Packing size 2120*225*1320mm
N.W.(KGS) 60
G.W.(KGS) 82





Powerful sofware: with iboard whiteboard software, for zoom in ,zoom out, ppt presentation,meeting room,etc.

LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 4

Packing: 1pc/carton, optional to be with wooden crate or pallet

LCD Smart Board USB HDMI TYPE-C Port Wifi Interactive Whiteboard TV OPS Screen Monitor For Teaching Video Room 86 Inch 5
