| Place of Origin: | CHINA |
|---|---|
| Brand Name: | iBOARD |
| Certification: | CE,ROHS,FCC,ETC. |
| Model Number: | ZS1-75 |
| Minimum Order Quantity: | 1set |
| Price: | USD1400-1600/set |
| Packaging Details: | carton box, left and side board in one box, display panel in one box,optional to have wooden crate or pallet |
| Delivery Time: | 15-20 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000 set per month |
| Panel Size: | 75"/86"optional | Android Version: | 8/9/11 Optional |
|---|---|---|---|
| Camera: | Out-connected Or Built In Optional | Mic: | Out-connected Or Built In Optional |
| Air Share: | Supporting | Applications: | School/office/meeting Room/auditorium |
| Side Bar: | Optional To Show On Left And Right Board | Annotation Software: | Supporting |
| High Light: | 86 inch Android Touch Panel Display,School Meeting Kids Intelligent Blackboard,3840*2160 auditorium Intelligent Blackboard |
||
Optional to have Camera or Mic built in or out-connected by USB port.
Optional to have air share function. max. support 4 or 9 screens at one time .
| Product model | TE-ZS1-86 |
| Panel type | DLED |
| Resolution | 3840*2160 |
| Brightness | 350 cd/㎡ |
| Contrast ratio | 1200:1 |
| Display area | 1895.04*1065.96mm(85.6 inch) |
| Display ratio | 16:9 |
| View angle | 178° |
| Color | 10bit,10.7billion colors |
| Video System | PAL,NTSC,SECAM |
| Sound System | D/K, B/G, I,M |
| Android system | 8.0 |
| Rom EMMC | 32G |
| RAM DDR3 | 4G |
| VGA input support resolution | 640*480/800*600/1024*768/1280*768/ 1280*800/1280*960/1280*1024/1360*768/1440*900/1600*1200/1920*1080@60Hz |
| Touch response time | <15ms |
| Input ports |
Rear:HDMI 2.0 *2; VGA *1; Audio*1(together with VGA connection); USB 3.0 *1; USB 2.0*1, RJ45 *1, SD CARD *1; AV-IN*1(support only Audio in); YPbPr *1; RS232 *1; USB Touch Port (B)*1; Wifi*1,DP *1 Front:1*HDMI(Max support 3840*2160/60Hz),1*TOUCH USB,3* USB, 1*Type-c |
| Output ports | Rear:AV-out*1; HeadPhone*1; SPDIF*1;HDMI *1 |
| Front buttons | 11KEY(POWER,SOURCE,MENU,VOL+,VOL-,CH+,CH-,PC,ES,ENTER,HOME) |
| Rating voltage | AC(100-240)V～50/60HZ |
| Rating power | 3.5A |
| Work temperature | 0°C～40°C |
| Touch points | 20 |
| Touch object | Finger or pcap pen |
| Touch technology | Capacity |
| Accuracy | <2mm |
| Continuous response time | <8ms |
| Cursor speed | >240 dot/s |
| Touch interface | USB |
| Touch system support | WINDOWS /LINUX/MAC /Android |
| Touch times | Same position more than 60000000 times |
| Accessories | Touch pen x 1 |
| Touch USB(1.5M) x 1 | |
| Power cable(1.8M) x 1 | |
| Remote controller x 1 | |
| Product dimension | 4200*1306.5*127.6mm |
| Package dimension |
2172*280*1457mm *1 1250*235*1427mm*1 |
| N.W. | TBD |
| G.W. | TBD |
Middle display size optional :75" and 86“
Optional product series:QS/XP/YL series, you could contact us for details if interested in .
