iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom

Basic Information
Place of Origin: China
Brand Name: Intelligent nano blackboard,86 Inch
Certification: CE CF FCC
Model Number: TE-GR-86
Minimum Order Quantity: 1
Price: 1800USD-2500USD
Packaging Details: Carton or wooden packaging, oem available
Delivery Time: 25 working days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20000 units/month
LCD Type: DLED Physical Resolution Of LCD: 3840*2160
Brightness: 350 Cd/㎡ Contrast Ratio: 4000:1
Display Area: 1895.04*1065.96mm(85.6 Inch) Screen Scale: 16:9
Viewing Angle: 178° Video Format: PAL、NTSC、SECAM
High Light:

86'' Smart Nano Interconnection Blackboard

,

Android 9.0 Intelligent Blackboard

,

School Classroom Intelligent Blackboard

Intelligent Interactive Blackboard for School Education
iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 0


Interconnected interactive whiteboard solution solve the problem that interactive whiteboard do not support chalk/ink pen writing and green board/whiteboard writing contents cannot be saved. Through this solution can make writing contents converted to digital page and share via QR code, this solution can combine with interactivce whiteboard, also can combine with IFPD to use.

Specification:
Appearance
To match with the main display unit
Size
Customized as per the height of main display unit
Surface Selection
Whiteboard/Greenboard
Touch Technology
Infared touch
Touch method
Finger, Pointer or any other opaque object
Touch
Support Touch ON/OFF via hotkey
Gesture Recognition
Support
File Saving
Support saving files as PPT/Word/PDF/image
format.
Touch Point
10
Cursor Speed
180 dot /s
Touch Resolution
32768x32768
Effect Touch Object Size
>8mm
Touch Method
Finger or Pen
Positioning Accuracy
<2mm
Touch lifetime
More than 60,000,000 single touch or click
Connecting Port
USB 2.0
Operating System
Windows 2000, Windows XP, Windows Vista,
Windows 7, Windows 8.1,Windows 10, Linux, Mac,
Android
Power Supply
USB power supply DC 4.6V- 5.0V <1W ( 200mA at
5V)
Working Condition
Indoor or Outdoor
Storage
Temperature: -30°C~60°C Humidity: 0%~95%
Operation
Temperature: -10°C~45°C Humidity: 10%~90%


LCD Screen Specification:

Products nameTE-GR-86
LCD typeDLED
Physical resolution of LCD3840*2160
Brightness350 cd/㎡
contrast ratio4000:1
Display area1895.04*1065.96mm(85.6 inch)
Screen scale16:9
viewing angle178°
Color10bit,10.7
Video formatPAL,NTSC,SECAM
Sound SystemD/K, B/G, I,M
Android system9.0
Android system EMMC32G
Android system DDR33G
Computer VGA input support resolution640*480/800*600/1024*768/1280*768/ 1280*800/1280*960/1280*1024/1360*768/1440*900/1600*1200/1920*1080@60Hz
Touch first response time<15ms
Input port

Front:2*HDMI2.0(up to3840*2160/60Hz),1*VGA+AUDIO,1*USB 2.0,1*USB 3.0,1*TOUCH-USB,1*RS232,1*TF卡,1*LAN IN(10M/100M),1*WIFI(2.4G/5G),1*Bluetooth(support4.0),1*standardOPS(up to3840*2160/60Hz, bulid-in 10M/100M LAN)
Front:1*HDMI(Max支持3840*2160/60Hz),1*TOUCH USB,3*复用USB

Output portPost output:1*COXIAL,1*EARPHONE
Front button11KEY(POWER,SOURCE,MENU,VOL+,VOL-,REC,A.Blue,PC,ES,RATIO,HOME)
Rated voltageAC(100-240)V~50/60HZ
Rated current3.5A
Working temperature0°C~40°C
Support touch points20
Touch modelfinger or capacitive pen
Positioning technologyCapacitance Technology
positioning accuracy<2mm
Continuous response time<8ms
Cursor speed>240点/mm
Touch screen system communication portUSB
operating systemSupport WINDOWS/LINUX/MAC /Android
Touch timesMore than 60 million times in the same location
AccessoriesTouch pen x 1
 USB(touch line1.5M) x 1
 power cable(1.8M) x 1
 Installation CD x 1
 Remote control x 1
 warranty card x 1
Bare metal size4200*1306.5*127.6mm

iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 1iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 2iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 3iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 4
Certificate:
iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 5
Exhibition:
iBoard 75'' 86'' Intelligent Smart Nano Interconnection Blackboard LED Android 9.0 For School Classroom 6

FAQ:
1. Q: Are you a factory?
A: Yes, we are a factory. We're located in Shenzhen China.
2. Q: How can I trust your product quality?
A: Quality is what we put first over the last 15 years. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE & ROHS & ISO & FCC etc.
3. Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly.
4. Q: Do you have MOQ?
A: Generally, our MOQ is 1 pcs. But the larger the order is, the more discounts will be given.
5. Q: Could you offer the OEM&ODM service?
A: Yes, we can. We've been providing OEM&ODM service for many world-class companies for over 15 years.
6. Q: What's the leading time?
A: The leading time for sample would be 3-7 days. As for large order, it takes about 25 days.
