| Place of Origin: | China |
|---|---|
| Brand Name: | IBOARD |
| Certification: | CE,FCC,ROHS,WEEE,etc. |
| Model Number: | TE-XP-86 |
| Minimum Order Quantity: | 10PCS |
| Price: | USD1500-1650/PC |
| Packaging Details: | carton box or could be with extra wooden crate or pallet |
| Delivery Time: | 15-20 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000pcs per month |
| Model: | Interactive Touch Screen Whiteboard Anti Blue Eyes Protection Multi Touch Display | Material: | Aluminum |
|---|---|---|---|
| Color: | Black Or Grey Or OEM | Brightness: | 350cd/m3 |
| Andriod Verison: | 9.0 With 3+32G | Flash: | 16G/32G EMMC |
| Display Ratio: | 16:9 | Operation OS: | WINDOWS/ANDROID/MAC/LINUX |
| Applications: | School/office/lab/science/family,etc. | Continuous Response Time: | Less Than 8ms |
| High Light: | 32G Smart Whiteboard For Teaching,Anti Blue Smart Whiteboard For Teaching,32G smart board for teaching |
||
Interactive Touch Screen Whiteboard Non Air Gap Temper Glass USB 2.0 3.0 Anti Blue Screen Cast Built in Andriod 9.0
Features:
1, 3840*2160(4K) DLED Display type, perfect display performance
2, Android 9.0 OS,latest Android version for touch monitors with 2+16G or 3+32G
3, Latest Infrared touch technology, 1/2/4/6/10points multi touch, high speed and smoothly
4, Touch support Windows, Linux, Android and Mac OS, and each system can provide suitable interactive educational software
5, Touch support Chrome OS
6, with 3 multi use front USB port, not only work in Android and OPS, but also can pass through the external PC USB, take more convenience to teachers
7, with light sensitive sensor, protect the user’s eyes smartly
8, N.W. no more than 38KG(65"), much easier for delivery and installation
9, multi input annotation software, built-in handwriting recognition (Optional), much easier make note when teaching or having meeting
10, optional magnetic penholder, can stick the magnetic pen on the frame
11, 11 front buttons, the most numbers in the market now, much easier for users operate the machine
12, highest screen display area, black area of scree no more than 2mm,glass thickness 4mm
13, built-in user guide, user can click the guide at the home page, much easier for know how to use the machine
14, optional front Type-C port, support both video play and USB function
15, bulit-in video conference software, support video call after connect to camera
16, bulit-in screen share software, support screen projection
| Model | TE-XP-65 | TE-XP-75 | TE-XP-86 |
| Display size | 1428.5*803.5mm | 1650.2*928.3mm | 1896.5*1066.5mm |
| Product size | 1469.1*935.8*92.4mm | 1695.6*1066*96.1mm | 1942*1203.6*93.9mm |
| Front Keys |
POWER,SOURCE,MENU,VOL+,VOL-,REC,A.Blue,PC,ES,RATIO,HOME |
||
| Input ports |
Back IO input:2*HDMI2.0(up to3840*2160/60Hz),1*VGA+AUDIO,2*USB 2.0,1*TOUCH-USB,1*RS232,1*TF,1*LAN IN(10M/100M),1*WIFI(2.4G/5G),1*Bluetooth,1*OPS(up to3840*2160/60Hz, bulid-in 10M/100M LAN) Front IO input:1*HDMI(Max supporting3840*2160/60Hz),1*TOUCH USB,3*USB |
||
| Output ports |
Back IO OUTPUT:1*COXIAL,1*EARPHONE |
||
| Side bar | NO | NO | NO |
| Andriod version | 9.0 | 9.0 | 9.0 |
| Model | TE-XP-65 | TE-XP-75 | TE-XP-86 |
| Touch technology | Infrared technology | ||
| Rated Voltage |
AC(100-240)V～50/60HZ |
||
| Rated current | 2.5A (including OPS) | ||
| Touch points | 1/2/4/6/10 | ||
Packing details:
| Model | TE-XP-65 | TE-XP-75 | TE-XP-86 |
| Packing size | 1646*240*1050mm | 1873*240*1204mm | 2120*240*1353mm |
| N.W. | 38KGS | 56KGS | 72KGS |
| G.W. | 52KGS | 73KGS | 93KGS |
| Packing accessories | Touch USB cable*1, HDMI cable*1,Power supply cord*1,Touch pen*2,Remote controller,Warranty card*1 | ||
Certificates: High quality passed CE,FCC,EMC,ROHS,WEEE,etc.
