IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K

Basic Information
Place of Origin: CHINA
Brand Name: iBoard
Certification: CE/FCC/ROHS
Model Number: YL5-65
Minimum Order Quantity: 1 Piece
Price: USD900-USD1800/unit
Packaging Details: Carton or wooden packaging, oem available
Delivery Time: 10-25 Working Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 units/month
Brand Name: IBoard Or OEM Product Name: 65'' Infrared Interactive Flat Panel
Model: YL5 Size: 65 Inch
Touch Technology: Infrared Touch Touch Ways: Finger Or Any Opaque Objects
Touch Points: 10 Points Or More Support OPS: Yes, One OPS Slot (Optional)
High Light:

OPS Slot LED Interactive Whiteboard

,

3840x2160 IR LED Interactive Whiteboard

,

Aluminium Frame IBoard Interactive Whiteboard

65'' IR Interactive Flat Panel Display

Specifications

DISPLAY
Screen Type LED Display Ratio 16:9
Resolution 3840(H) x 2160(V) Display Area 1428.5X803.5 mm
Brightness 350 cd/m2 Color Depth 10bit(R), 1.07Billon colors
Contrast 1200:1 Life Time 50,000 Hrs
ANDROID SYSTEM
Android Version Android 8.0 GPU ARM Mali-m51450MHz
CPU

Dual Cores ARM Cortex-A73

Dual Cores ARM Cortex-A53

RAM 4G,(8Gbit×4);DDR4;
Dominant Frequency 1.5G ROM 32G
DISPLAY CONNECTION PORTS
Input Ports (Front)

HDMI 1.4*1;USB Touch Port (B)*1,USB*3(multi use for both Android,OPS and external PC)

USB-C(optional)

Output Ports(back)

AV-out*1; HeadPhone*1; SPDIF*1;

HDMI *1

Input Ports (Back)

HDMI 2.0 *2; VGA *1; Audio*1(together with VGA connection); USB 3.0 *1;

USB 2.0*1, RJ45 *1, SD CARD *1; AV-IN*1(support only Audio in); YPbPr *1; RS232 *1; USB Touch Port (B)*1; Wifi*1,DP *1


Sensing Type Infrared Touch Writing Style Finger; Stylus,any opaque object
Positioning resolution 32767 x 32767 Communication Mode Full-speed USB (Plug and Play)
Scanning Speed 4ms Surface Glass 4mm tempered Glass
Response size ≥Φ3mm OS support Android, Windows, Linux, Mac, Chrome
Built-in Camera Support 2K or 4K
Built-in Speakers 2*15W
INTERNET
Ethernet 802.3 10/100 Wifi

IEEE802.11 a/b/g/n Dual Band 2.4GHz/5 GHz

Or IEEE802.11an 2.4GHz

Bluetooth 4.2
ACCESSORIES
Touch pen x 2
Touch USB (A-B 1.5M) x 1
HDMI cable(2M) x 1
Power cable(1.8M) x 1
Remote controller x 1
AMBIENT CONDITIONS
Operation Temperature 0°C~40°C Operation Humidity 10% - 90%
Storage Temperature -10°C~560°C Storage Humidity 10% - 90%


IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 0IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 1

IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 2IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 3IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 4IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 5IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 6

Certificates

Our products meet the certification requirements of most of countries in the world and have complete certificates.

IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 7

Exhibition:

IR LED Interactive Whiteboard Ultra Slim Aluminium Frame Interactive Touch Panel Infrared 4K 8





























































































FAQ:

1. Q: Are you a factory?
A: Yes, we are a factory. We're located in Shenzhen China.
2. Q: How can I trust your product quality?
A: Quality is what we put first over the last 15 years. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE & ROHS & ISO & FCC etc.
3. Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly.
4. Q: Do you have MOQ?
A: Generally, our MOQ is 1 pcs. But the larger the order is, the more discounts will be given.
5. Q: Could you offer the OEM&ODM service?
A: Yes, we can. We've been providing OEM&ODM service for many world-class companies for over 15 years.
6. Q: What's the leading time?
A: The leading time for sample would be 3-7 days. As for large order, it takes about 25 days.
